GoldSeal 1 1/2″ (40mm) Normally Closed Gas Solenoid Valve – 230V

£105.00 Incl VAT: £126.00

The Gold Seal GSV solenoid valves are widely used in gas distribution to provide isolation and emergency shut-off. They can be used with various hydrocarbon gases including natural gas, methane and liquid petroleum gas.

Please note: Delivery within 5 working days for this product.

For large quantities, help with installation, servicing or specification, contact us to discuss contract pricing and credit accounts.

Description
Downloads

Description

Size: 1 1/2″ (40mm) DN40 Screwed.
Normally Closed: The GSV solenoid valves will normally be in the closed position.
Visual Indication: Blue indicator light when energized.
Durable Construction: Made from a high quality aluminum alloy offering robust performance in any environment.
Fast actuation: Opening & closing time < 1 second.
High Operating Frequency: Up to 20 times per minute.
High Safety Standards: Compliant with EN 161 with an IP54 rating.
Multiple Ports: G¼ holes on both sides of the valve body and at the bottom for various applications but notably a CPI (closed position indicator) or gas proving system.
Voltage: Operates on 230Vac & 110Vac.
Easy Installation: Clearly marked connections, low voltage wiring and push-fit connections make the system very simple to install.
3 Year Warranty: Covered by S&S Northern Ltd with a 3 year warranty.
